How To Repair Chrysler/Dodge Minivan Instrument Cluster Problems -EricTheCarGuy

How To Repair Chrysler/Dodge Minivan Instrument Cluster Problems is part of the Fixing it Forward series. Not long after Barbara got her van back, she called me and told me her instrument cluster was freaking out. With a little research I found out the problem might be the solder joints on the back of the instrument cluster circuit board. I decided to give the repair a try and made this video.

If you need to know how to remove an instrument cluster from a Chrysler or Dodge minivan, this video will show you how to do that. The video also shows how to disassemble the instrument cluster for repair and how to solder the problem joints.

This money saving repair won't take that long and may save you from buying an entire cluster. This video also shows how to check the instrument cluster bulbs as well as replace them.

After removing and inspecting the instrument cluster I think the problem might be the ignition switch. Every time I moved the wiring the key chime would go on and off. This usually indicates a loose connection. If you’re doing this repair, you might want to check the ignition switch while you’re in there.

Thanks for watching!

You can donate to Fixing it Forward here: gofundme.com/3a3s27dg

The best place for answers to your automotive questions: http://www.ericthecarguy.com

Discussion about this video: http://www.ericthecarguy.com/kunena/18-The-EricTheCarGuy-Video-Forum/60304-how-to-repair-dodge-minivan-instrument-cluster#148799

Tools

Weller Soldering Iron: http://www.jbtoolsales.com/weller-wes51-analog-soldering-station-with-power-unit-pencil-new#oid=1002_1

DVOM: http://www.jbtoolsales.com/electronic-specialties-480a-auto-ranging-digital-multimeter#oid=1002_1
